Danfoss ICLX150 Two-Step Solenoid Valve
Danfoss
Description
The Danfoss ICLX150 is a two-step opening solenoid valve designed for DN150 pipelines. It ensures smooth operation and reduced pressure surges, making it ideal for industrial applications requiring reliable and efficient flow control. This valve provides controlled medium flow in two distinct stages, offering superior performance and durability.
Product Details
| Model | Nominal Diameter (DN) (mm) | Nominal Pressure (PN) (MPa) | Body Material | Connection Type | Application | Operation Type | Pressure Environment |
|---|---|---|---|---|---|---|---|
| ICLX100 | DN100 | 4 | Cast Steel | Welding | Air Conditioning, Refrigeration, Freezing | Normally Closed | High Pressure |
| ICLX125 | DN125 | 4 | Cast Steel | Welding | Air Conditioning, Refrigeration, Freezing | Normally Closed | High Pressure |
| ICLX150 | DN150 | 4 | Cast Steel | Welding | Air Conditioning, Refrigeration, Freezing | Normally Closed | High Pressure |
| EVM 027B1130 | DN15 | 6 | Cast Steel | External Thread | Air Conditioning, Refrigeration, Freezing | Normally Open | High Pressure |
| Attribute | Value |
|---|---|
| Gross weight | 0.4 Kilogram |
| Net weight | 0.332 Kilogram |
| Volume | 0.647 Liter |
| EAN | 5702423059546 |
| Type | MBS 5100 |
| Product group | Sensors |
| Product Name Description | Pressure transmitter |
| + supply | Pin 1 |
| - common | Pin 2 |
| Accuracy, max. [±FS%] | 0.3 % |
| Accuracy, typical [±FS%] | 0.1 % |
| Adj. zero point and span | No |
| Ambient temperature range [°C] [max] | 85 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 185 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | CEC UL US UL Recognized |
| CE evaluated | Yes |
| China RoHS compliance | Out of scope |
| Compensated temp. range [°C] [max] | 80 °C |
| Compensated temp. range [°C] [min] | 0 °C |
| Compensated temp. range [°F] [max] | 176 °F |
| Compensated temp. range [°F] [min] | 32 °F |
| Contains batteries | No |
| EEE category | 5 small equipment (any external dimension < 50 cm) |
| Electrical conn. Male/Female | Male and Female |
| Electrical connection | Angular connector |
| Electrical connection size | Pg 11 |
| Electrical connection standard | EN 175301-803-A |
| Enclosure rating IP | IP65 |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| Flush diaphragm | No |
| High Clipping Level | 22.4 |
| In scope of WEEE | Yes |
| International Article Number | 5702423059546 |
| Intrinsically safe | No |
| Low Clipping level | 3.6 |
| Medium temperature range [°C] [max] | 85 °C |
| Medium temperature range [°C] [min] | -40 °C |
| Medium temperature range [°F] [max] | 185 °F |
| Medium temperature range [°F] [min] | -40 °F |
| Non-linearity BFSL [±FS%] | 0.2 % |
| Output signal | Current |
| Output signal [mA] [max] | 20 mA |
| Output signal [mA] [min] | 4 mA |
| Overload pressure max. [bar] | 20 bar |
| Packing format | Multi pack |
| Pressure connection notes | With flange |
| Pressure connection size | 1/4 |
| Pressure connection standard | ISO 228-1 |
| Pressure connection type | G |
| Pressure Male/Female | Female |
| Pressure range [bar] [max] | 6 bar |
| Pressure range [bar] [min] | 0 bar |
| Pressure range [psi] [max] | 87 psi |
| Pressure range [psi] [min] | 0 psi |
| Pressure reference | Gauge (relative) |
| Pulse-snubber | No |
| Quantity per packing format | 8 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Response time max. [ms] | 4 ms |
| SCIP dossier no. | 16d2efc6-64f3-4a4e-ae98-a3fd7ce0218d |
| SCIP dossier product name | AKS/MBS |
| Specification key | MBS 5100-1811-A6DB04-4 |
| Supply voltage [V] DC [max] | 32 V |
| Supply voltage [V] DC [min] | 9 V |
| Test Signal | PIN 3 |
| UL evaluated | Yes |
