Description

STC-8080A+ is a universal digital temperature controller for light commercial refrigeration and HVAC systems. Delivers precise temperature control, user-friendly configuration, and stable operation for display cases, cold storage, and food service equipment.

Product Details

Model: STC-8080A+

Key Features

1. Adjustable Alarm Delay

The temperature alarm delay is adjustable from 0~99 minutes after power-on, avoiding false alarms caused by high temperature during initial startup.

2. Upper & Lower Limit Temperature Control

Separate settings for user parameters and administrator parameters, with upper/lower limit restriction on user-set values. Prevents cargo loss caused by incorrect parameter settings due to misoperation.

3. Adjustable Alarm Deviation

The temperature over-limit alarm deviation is adjustable from 0~50, meeting diverse usage requirements.

4. Proportional On/Off in Case of Sensor Failure

When the sensor fails, the controller operates the compressor in proportional on/off mode, effectively avoiding the risk of temperature out of control after sensor failure.

International Safety & Compliance Certifications

Our products have passed a full range of international safety and environmental certifications, ensuring global market access and reliable performance:

CE Certification: Mandatory EU safety certification, complying with EU safety, health and environmental standards.
UL Certification: Authoritative US safety certification for electrical and electronic products.
ETL Listed Certification: OSHA-recognized North American safety certification, equivalent to UL.
CQC EMC Certification: China's national-level quality and electromagnetic compatibility certification.
RoHS Compliance: EU Restriction of Hazardous Substances directive, meeting global green manufacturing requirements.

STC-8080A Temperature Controller Specifications
Measurement Range	-50°C ~ +99°C	Temperature Control Range	-40°C ~ +50°C
Measurement Accuracy	±1°C	Power Supply	220VAC 50HZ
Resolution	0.1°C	Installation Dimensions	71*29mm
Housing Material	ABS Flame-Retardant Plastic	Operating Humidity	20%~85%RH
