Danfoss EVRA 32 042H1126 Refrigerant Solenoid Valve 42.0 bar, UL Listed, Made in DenmarkDescription
The Danfoss EVRA-32 (042H1126) is a high-performance servo-operated solenoid valve designed for industrial refrigeration systems. Rated at a maximum working pressure of 42.0 bar (610 psig), it features a maximum operating pressure differential of 21 bar (AC 10W) and 14 bar (DC 20W). Made in Denmark and UL certified, this valve provides reliable shutoff control for ammonia and fluorocarbon refrigerants.
Product Details
Danfoss EVRA 32 042H1126 Servo-Operated Solenoid Valve
Key Features & Benefits
High Pressure Rating: Maximum working pressure of 42.0 bar (610 psig), with a maximum operating pressure differential of 21 bar (for AC 10W coils) and 14 bar (for DC 20W coils), suitable for high-pressure industrial refrigeration applications.
Servo-Operated Design: Pilot-operated mechanism allows for reliable opening and closing with minimal power consumption, ideal for large-diameter, high-flow refrigerant lines.
Wide Refrigerant Compatibility: Compatible with ammonia, R22, R134a, R404A, and other common refrigerants, making it versatile for diverse system designs.
Robust Construction: Cast iron valve body provides excellent corrosion resistance and mechanical strength, ensuring long service life in harsh industrial environments.
Certified Quality: UL listed and manufactured in Denmark to Danfoss' strict global quality standards, ensuring compliance with international safety and performance norms.
Flexible Installation: Can be installed in any orientation, suitable for liquid, suction, and discharge line applications, including pump-down cycles, defrost systems, and emergency shutoff functions.
Application Scenarios
Large industrial cold storage warehouses and freezers
Ammonia refrigeration systems and industrial process cooling
Water chillers and heat pump systems
Commercial refrigeration and supermarket display racks
HVAC&R system maintenance, retrofitting, and new installations
| Parameter | Specification |
|---|---|
| Brand | Danfoss |
| Series | EVRA |
| Model Number | EVRA 32 |
| Part Number | 042H1126 |
| Product Type | Servo-Operated Refrigerant Solenoid Valve |
| Maximum Working Pressure (MWP) | 42.0 bar (610 psig) |
| Max Operating Pressure Differential (MOPD) | 21 bar (AC 10W), 14 bar (DC 20W) |
| Body Material | Cast Iron |
| Compatible Refrigerants | Ammonia, R22, R134a, R404A, etc. |
| Certifications | UL Listed |
| Origin | Made in Denmark |
| Application | Industrial Refrigeration, Cold Storage, Chillers, HVAC&R Systems |
| Model | Nominal Diameter (DN) (mm) | Nominal Pressure (PN) (MPa) | Application Range | Body Material | Connection Type | Operation Mode | Pressure Environment |
|---|---|---|---|---|---|---|---|
| EVRA32 | DN32 | 42 | Air Conditioning, Refrigeration, Freezing | Cast Steel | Welding | Normally Closed | High Pressure |
| EVRA40 | DN40 | 42 | Air Conditioning, Refrigeration, Freezing | Cast Steel | Welding | Normally Closed | High Pressure |
| 032F2335 Repair Kit | DN15 | 42 | Air Conditioning, Refrigeration, Freezing | Cast Steel | Welding | Normally Closed | High Pressure |
| Attribute | Value |
|---|---|
| Gross weight | 4.904 Kilogram |
| Net weight | 4.42 Kilogram |
| Volume | 7.56 Liter |
| EAN | 5702422171331 |
| Type | EVRA 32 |
| Product group | Solenoid valves |
| Product Name Description | Solenoid valve |
| Actuator system [mm] | 13.5 mm |
| Ambient temperature | -40 - 80 °C |
| Ambient temperature range [°F] [max] | 175 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | C UL US LISTEDEACLLC CDC TYSK |
| Body material | Cast iron |
| China RoHS compliance | Out of scope |
| Coil | No |
| Connection material | Steel |
| Connection standard, inlet | EN 10220 |
| Connection standard, outlet | EN 10220 |
| Contains batteries | No |
| Cv value [gal/min] | 18.5 gal/min |
| Direction | Straightway |
| EU RoHS compliance | Out of scope |
| Flow direction indicator | Embossed 1-way arrow |
| Function | NC |
| Inlet connection type | Butt weld |
| Inlet size [in] | 1 1/4 in |
| Kv value [m³/h] | 16 m³/h |
| Manual operation option | Yes |
| Max. Working Pressure [bar] | 42 bar |
| Max. Working Pressure [psig] | 610 psig |
| MaxOPD[bar] 10W AC | 21 bar |
| MaxOPD[bar] 12W AC | 25 bar |
| MaxOPD[bar] 20W DC | 14 bar |
| MaxOPD[psi] 14W AC | 300 psi |
| Medium temp. range note | Defrost max 130°C/265°F |
| Medium temperature range [°C] [max] | 105 °C |
| Medium temperature range [°C] [min] | -40 °C |
| Medium temperature range [°F] [max] | 221 °F |
| Medium temperature range [°F] [min] | -40 °F |
| MinODP [bar] | 0.2 bar |
| MinODP [psi] | 2.9 psi |
| Orifice size [mm] | 22.23 mm |
| Outlet connection type | Butt weld |
| Outlet size [in] | 1 1/4 in |
| Packing format | Single pack |
| Parts Program name | EVRA / EVRAT |
| Product accessories | Solenoid valve accessories |
| Quantity per packing format | 1 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Refrigerants | R134aR22R401AR402AR404AR407AR407BR407CR407FR409AR410AR421AR502R507AR717 |
| SCIP dossier no. | d38f86ba-12bb-4e70-8d9f-ec3fd58b7365 |
| SCIP dossier product name | EVRA EVRAT |
| Serviceable | Solenoid valve spare parts |
| Type designation | Solenoid valve |
| UL evaluated | Yes |
| Valve operation | Servo-piston |
